Asus ROG STRIX Z690-A GAMING WIFI D4, Intel Z690, 1700, ATX, 4 DDR4, HDMI, DP, Mini DP, 2 Thunderbolt, Wi-Fi, 2.5G LAN, PCIe5, R
£387.89
VAT included
Intel Z690 LGA 1700 ATX motherboard with PCIe 5.0, 16+1 DrMos, Two-Way AI Noise Cancelation, AI Overclocking, AI Cooling, AI Networking, WiFi 6 (802.11ax), Intel 2.5 Gb Ethernet, four M.2 slots with heatsinks PCIe 4.0 NVMe SSD support, M.2 backplate, PCIe Slot Q-Release, USB 3.2 Gen 2x2 Type-C, SATA and AURA Sync RGB lighting
- Intel LGA 1700 socket: Ready for 12th Gen Intel Core, Pentium Gold and Celeron Processors
- Optimal Power Solution: 16+1 DrMos with ProCool II power connector, high-quality alloy chokes and durable capacitors to support multi-core processors
- Optimised Thermal Design: Integrated I/O cover and VRM heatsinks with high conductivity thermal pad, four onboard M.2 heatsinks and M.2 backplate for the M.2_1 slot
- High-performance Networking: On-board Intel WiFi 6 (802.11ax) and Intel 2.5 Gb Ethernet with ASUS LANGuard
- Best Gaming Connectivity: Supports HDMI 2.1 and DisplayPort 1.4 output, four M.2 slots, as well as USB 3.2 Gen 2x2 Type-C
- Intelligent Control: ASUS-exclusive AI Overclocking and Two-Way AI Noise Cancelation to simplify setup and improve performance
- DIY Friendly Design: PCIe Slot Q-Release, M.2 Q-Latch, ROG Reusable Cable Organizer, pre-mounted I/O shield, BIOS FlashBack button, and Clr CMOS button
- Unmatched Personalisation: ASUS-exclusive Aura Sync RGB lighting, including an RGB header and three addressable Gen 2 headers
- Industry-leading Gaming Audio: High fidelity audio with ALC4080 with Savitech SV3H712 amplifier, along with DTS Sound Unbound and Sonic Studio III
- Renowned Software: Bundled AIDA64 Extreme 60 days free trial version and intuitive UEFI BIOS dashboard with integrated MemTest86
ROG STRIX Z690-A GAMING WIFI D4
The ROG Strix Z690-A Gaming WiFi D4 motherboard deploys robust power delivery and cooling to unleash the full force of 12th Gen Intel Core processors, all orchestrated by ASUS-exclusive intelligent controls that deliver advanced user experiences. Meanwhile, onboard WiFi 6 and ample PCIe 4.0 M.2 slots bring the speed that you need, and DIY-friendly innovations help simplify the PC building process. To top it all off, Strix Z690-A Gaming WiFi D4 dazzles with customizable RGB lighting and a refined brushed-metal finish.
All-Round Performance
ROG Strix Z690-A Gaming WiFi D4 provides up-rated power delivery and optimised cooling to push any gaming build to its limits. Intelligent controls enable easy management of overclocking, cooling and networking settings, while Two-Way Al Noise Cancelation ensures crystal-clear in-game communication. ROG Strix Z690-A Gaming WiFi D4 is armed with all the essentials required to create a gaming PC with top-tier performance.
Leading Connectivity
ROG Strix Z690-A Gaming WiFi D4 delivers wickedly fast connectivity for supersmooth online experiences and ultrafast data transfers. Add alongside those perks, we've managed to cram in an advanced audio solution that allows you to pick out the smallest cues and home in on your opponents.
Play In Style
Pair ROG Strix Z690-A Gaming WiFi D4 with other products from the diverse ROG ecosystem to create a fully customised gaming setup
that reflects your personal style.
ROG Gives You More
ROG-exclusive software utilities deliver intuitive audio tuning and gaming enhancements so you can configure your gaming build the way you want To further aid system setup and performance tuning, the highly acclaimed AIDA64 and MemTest86 utilities have also been added to the mix.
UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.
5-Way Optimisation
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans.
Click here for full details
90MB18K0-M0EAY0
Data sheet
- .
- 1 x AURA RGB1 x Clear CMOS1 x CPU Over Voltage jumper1 x 12-1 pin Front Panel Audio1 x S/PDIF Out1 x SPI TPM (14-1pin)1 x 20-3 pin System Panel1 x Thermal Sensor1 x Thunderbolt
- Wireless
- Wi-Fi 62x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency bandBluetooth v5.2
- RAM Speeds
- up to 5333(OC)
- Accessories
- 4 x SATA 6Gb/s cables 1 x ASUS Wi-Fi moving antennas 1 x Cable ties pack1 x M.2 Rubber Package1 x M.2 Q-Latch package1 x ROG key chain1 x ROG Strix stickers1 x ROG Strix thank you card1 x Support DVD1 x User guide
- USB Ports Supported
- 1 x USB 3.2 Gen 2x2 Type-C (at back)1 x USB 3.2 Gen2 Type-C (at back)2 x USB 3.2 Gen2 Type-A (at back)6 x USB 3.2 Gen1 Type-A (4 at back, 2 at mid-board)6 x USB 2.0 (2 at back, 4 at mid-board)1 x USB 3.2 Gen2x2 Type-C front panel connector
- Storage
- 6 x SATA III1 x M.2 (2242/2260/2280) - PCIe2 x M.2 (2242/2260/2280/22110) - PCIe1 x M.2 (2242/2260/2280) - SATA & PCIe
- RAID
- Intel Rapid Storage supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10
- Warranty
- 3 Years
- Motherboard Type
- Desktop
- Form Factor
- ATX
- Socket
- Intel 1700
- Chipset
- Intel Z690
- DDR Type
- DDR4
- RAM Technology
- DDR4 (Dual Channel)
- RAM Slots
- 4 x DIMM
- Maximum Memory
- 128GB
- LAN
- 2.5GB LAN
- Audio
- ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
- Back Panel I/O Ports
- 1 x USB 3.2 Gen2x2 Type-C3 x USB 3.2 Gen2 (2 Type-A, 1 Type-C)4 x USB 3.2 Gen1 Type-A2 x USB 2.01 x DisplayPort1 x HDMI1 x ASUS Wi-Fi Module1 x Intel 2.5Gb Ethernet5 x Audio jacks 1 x BIOS FlashBack button 1 x Clear CMOS button
- Internal I/O Connectors
- 1 x 4-pin CPU Fan1 x 4-pin CPU OPT Fan1 x 4-pin AIO Pump5 x 4-pin Chassis Fan1 x 24-pin Main2 x 8-pin +12V4 x M.2 (Key M) 6 x SATA 6Gb/s1 x USB 3.2 Gen2x2 connector Type-C1 x USB 3.2 Gen12 x USB 2.03 x Addressable Gen2
- CPU Support
- Click here for CPU support
- Package Type
- Retail
- Graphics Ports
- 1 x HDMI1 x DisplayPort1 x Mini DisplayPor2 x Thunderbolt 4 (USB Type-C) support DisplayPort 1.4 and Thunderbolt video outputs
- Additional Features
- See Overview
- Graphics
- Integrated Graphics**Graphics specifications may vary between CPU types
- M.2 Slot(s)
- Yes (M.2)
- No. LAN Ports
- 1 x LAN
- Max LAN Speed
- 2.5GB LAN
- RGB Lighting
- Yes (RGB)
- PCI/PCI Express
- 1 x PCIe 5.0 x161 x PCIe 3.0 x161 x PCIe 3.0 x1
- Wi-Fi
- Yes (Wi-Fi)
