Cooler Master Silencio S600 Mid Tower 2 x USB 3.2 Gen 1 Sound-Dampened Steel Black Case

SILENCIO S600
SILENCE HAS A SEQUEL
- Silencio Design
- Silencio Technology
- Sound Dampening Material
- Sound-Dampened Steel
- Top & Front Ventilation
- Reversible Steel Door

SILENCIO DESIGN
The Silencios minimalistic design cloaks its complexity. Design elements fine-tuned in form and function result in minimized noise and efficiently maintained system temperatures.

SILENCIO TECHNOLOGY
Behind the outer panels are pieces of meticulously placed sound dampening material. The development of the Silencio was driven by Soramas Cam64this allowed for the entire sound spectrum to be visually analyzed by source, resonance pattern, and frequency.

With the identification of peaks within certain frequency ranges, fine-tuning the Silencio for the dispersion of resonance was made possible, reducing the prominence of noise generated by system components. Every detail in design optimized the Silencio for thermal efficiency and silence, from the type of material used to its placement.

SOUND DAMPENING MATERIAL
The Silencio utilizes a combination of sound dampening materials, from thick soft foam to heavy mass-loaded vinyl, to precisely counter prominent frequencies.

VENTILATION
TOP:
For an even higher demand for ventilation, the top panels Sound Dampening Cover can be removed for unrestricted ventilation. An optional dust filter for the top panel ventilation is included, allowing the top panel and front panel work in conjunction to cool the system.

FRONT:
The front panel features a recurved vent, directing air in through the front bezel. The curve points downward, taking air in from the bottom, and straightens out to direct air in from either side of the steel front door.

REVERSIBLE STEEL DOOR
The steel front door features a reversible mounting system, capable of opening in either direction. To prevent vibrations, a softer, thicker material spans the steel structure in conjunction with a hinge system of magnets and rubber stompers.

SILENCIO FANS
Two Silencio FP 120mm PWM fans are pre-installed with rubber padding to reduce noise, featuring specially designed blades that allow both quiet operation and high air pressure.

Model Number
MCS-S600-KN5N-S00 (Steel Version)

Series
Silencio Series

Form Factor
Mid Tower

Colour
Black

Materials
Steel
Plastic
Sound Dampening Material

Dimensions ( L x W x H )
478mm x 209mm x 470.5mm (incl. Protrusions)
466mm x 209mm x 460.5mm (excl. Protrusions)

Motherboard Support
ATX
Micro ATX
Mini-ITX

Expansion
Slots: 7

Drive Bays
5.25": 1
3.5": 4
2.5": 5

I/O Panel
2 x USB 3.2 Gen 1 (formerly USB 3.0)
1 x 3.5mm Headset Jack (Audio+Mic)
1 x SD card reader

Pre-Installed Fans
Front: 1 x 120mm (PWM 800-1400 RPM)
Rear: 1 x 120mm (PWM 800-1400 RPM)

Fan Support
Front: 2 x 120 / 140mm
Top: 2 x 120 / 140mm
Rear: 1 x 120mm

Radiator Support
Front 120mm / 140mm / 240mm / 280mm
Top: 120mm / 240mm (requires removal of ODD cage / 35mm max motherboard component height)
Rear: 120mm

Clearance
CPU Cooler: 166mm (Steel Version)
GPU: 398mm
PSU: 180mm
Cable Routing: 18-26mm

Power Supply Support
Bottom Mount
ATX PS2

Dust Filerts
Top
Front
Bottom
