1 x USB 2.02 x USB 3.2 Gen11 x Front Panel Type C USB 3.2 Gen21 x Dr. Debug with LED1 x Power Button with LED1 x Reset Button with LED1 x Clear CMOS Button
PCI Express
AMD Ryzen CPUs (Matisse)3 x PCIe 4.0 x16AMD Ryzen CPUs (Pinnacle Ridge)3 x PCIe x16 SlotsAMD Ryzen CPUs (Picasso)1 x PCIe x16 Slot3 x PCIe 2.0 x1
Wireless
Intel 802.11ax WiFi ModuleSupports IEEE 802.11a/b/g/n/axSupports Dual-Band (2.4/5 GHz)Supports WiFi6 802.11ax (2.4Gbps)2 antennas - 2 (Transmit) x 2 (Receive)Supports Bluetooth 5.0 + High speed class IISupports MU-MIMO
2 x USB 3.2 Gen2 Thunderbolt Type-C (at back)10 x USB 3.2 Gen1 (6 at back, 4 at mid-board)2 x USB 2.0 (at mid-board)1 x Front Panel Type C USB 3.2 Gen2 Header
Storage
8 x SATA III1 x M.2 (2260/2280/22110) - PCIe1 x M.2 (2260/2280) - SATA & PCIe
7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
Back Panel I/O Ports
2 x Antenna1 x PS/2 Mouse/Keyboard1 x HDMI1 x DisplayPort 1.4 Input1 x Optical SPDIF Out2 x USB 3.2 Gen2 Thunderbolt 3 Type-C6 x USB 3.2 Gen12 x RJ-45 LAN1 x BIOS Flashback ButtonHD Audio Jacks
Internal I/O Connectors
1 x DisplayPort 1.4 Input1 x Power LED and Speaker1 x AMD Fan LED1 x RGB LED1 x Addressable LED1 x CPU Fan1 x CPU/Water Pump Fan3 x Chassis/Water Pump Fan1 x 24 pin ATX1 x 8 pin 12V1 x 4 pin 12V1 x Front Audio
CPU Support
Click here for CPU support
Package Type
Retail
Package Weight
0.0000 kg
4.9300 kg
Graphics Ports
1 x HDMI Port1 x DisplayPort 1.4
Additional Features
See Overview
Graphics
Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU
M.2 Slot(s)
Yes (M.2)
No. LAN Ports
2 x LAN
Max LAN Speed
10GB LAN
Specific References
EAN13
4717677339338
