3 x Serial ATA31 x HDD Power (4-pin)1 x Speaker (4pin)1 x Serial Port (8-pin)2 x SGPIO Header1 x Clear CMOS
PCI Express
PCIe 3.0 x 16 - SLOT7: Gen3 x16 link
Wireless
-
RAM Speeds
2133/2400/2666 MHz
USB Ports Supported
4 x USB 3.1 Gen 2 Type-A (at back)2 x USB 3.1 Gen 1 (at mid-board)2 x USB 2.0 ports (at back)
Storage
4 x SATA III1 x M.2 (2242) - SATA & PCIe
Warranty
3 Years
Motherboard Type
Server / Workstation
Form Factor
Mini ITX
Socket
Intel 1151 - Coffee Lake
Chipset
Intel C246
DDR Type
DDR4
RAM Technology
DDR4 (Dual Channel)
RAM Slots
2 x DIMM
Maximum Memory
32GB
Multi-GPU Support
-
LAN
Dual GB LAN
Audio
Realtek ALC892
Back Panel I/O Ports
1 x HDMI1 x VGA2 x USB 2.04 x USB 3.1 Gen22 x GB LAN (by Intel i210+ Intel i219LM)1 x Display Port3+1 CH audio with SPDIF1 x SPDIF
Internal I/O Connectors
1 x COM1 x SATA DOM1 x M.21 x OCuLink1 x Auxiliary Panel1 x TR11 x TPM3 x Fan (1CPU/1Front/1Rear)1 x ATX (4-pin)1 x DC IN (8-pin)1 x USB 3.1 (Gen1)1 x Front Panel (RST, HDLED, PLED, PERBTN)
CPU Support
Click here for CPU support
Package Type
Retail
Package Weight
0.8520 kg
Graphics Ports
1 x VGA1 x HDMI1 x DisplayPort
Additional Features
See Overview
Graphics
Supports Intel HD Graphics
M.2 Slot(s)
Yes (M.2)
No. LAN Ports
2 x LAN
Max LAN Speed
GB LAN
RGB Lighting
No
PCI/PCI Express
PCIe 3.0 x 16 - SLOT7: Gen3 x16 link
Specific References
EAN13
4717677336894
