Ace PSUs are certified RoHS compliant and with power factor control-giving you a safe and stable foundation to build your system from. Ace PSUs come with a superb 12cm fan that offers a quiet operation but with excellent cooling meaning you are working in a more peaceful environment and the right cooling ensures maximum lifespan of your products. Supplied with all the appropriate cables Ace provides maximum compatibility with popular CPU's and mainboards.
Key Features - Power Factor Control (PFC) - Cooling: 12cm Black Fan - New Version 1.3 / 2.03 - Silent with better ventilation - ATX 12V compliant for most CPUs and mainboards - Input Range : 230Vac, 5A, 50-60Hz - 2 x SATA Connectors - 3 x Molex Connectors - 20+4 Pin Motherboard Connector
Model Number A-600BR
Wattage 600W
Connections 1 x 20+4 Pin ATX 1 x 4+4 Pin EPS 1 x 6+2 Pin PCIe 2 x SATA Connectors 3 x 4-Pin Molex Connectors 1 x Floppy Drive Connectors
Input Voltage 230 VAC
Input Current 5A
Input Frequency Range 50-60Hz
PFC Yes Passive Power Factor Control
Power Good Signal 150-450 ms
Hold Up Time 1ms-40ms
Efficiency 75%
MTBF 100,000 Hours
Protection OVP / UVP/ OPP
Operational Temperature 45°C
Safety CE / ROHS
Cooling 120mm Black Fan
Noise < 17 dBA
What's In The Box PSU Manual Screws Cable Ties
Product Dimensions ( W x H x D ) 150mm x 85mm x 140mm
Packaging Dimensions ( W x H x D ) 230mm x 85mm x 140mm
