Asus PRIME X870-P, AMD X870, AM5, ATX, 4 DDR5, HDMI, 2 USB4, 2.5G LAN, 4x M.2
search
  • Asus PRIME X870-P, AMD X870, AM5, ATX, 4 DDR5, HDMI, 2 USB4, 2.5G LAN, 4x M.2

Asus PRIME X870-P, AMD X870, AM5, ATX, 4 DDR5, HDMI, 2 USB4, 2.5G LAN, 4x M.2

£259.40
VAT included
Stock status: Moderate
53 items
Delivered within 1-2 days.
Quantity

Delivery from %MINIMAL_DATE%




ASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors.


Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the PRIME X870-P motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It's designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.


  • Advanced AI PC-ready
  • 14+2+1 DrMOS
  • PCIe 5.0 x16 slot with full support for next-gen graphics card
  • DDR5 slots
  • Four M.2 slots
  • Realtek 2.5 Gb Ethernet
  • USB 40Gbps
  • HDMI
  • USB 10Gbps Type-A
  • Front USB 10 Gbps Type-C connector
  • SATA 6Gbps ports
  • USB 5 Gbps header
  • Aura Sync RGB lighting






Robust power design

Stable power is crucial for maximizing the performance of AMD processors. The PRIME X870-P is designed to meet the needs of high-core-count CPUs. It features 14(80A) + 2(80A) + 1(80A) power stages that integrate high-side and low-side MOSFETs and drivers into packages rated for up to 80 amperes each. This configuration ensures optimal power delivery, efficiency, stability and performance for both current and future AMD processors.
  • Eight-layer PCB design - Enhanced stability and overclocking.
  • ProCool connectors - Proprietary 8 + 8 pin connectors improve PSU connection.
  • Power Saving - Optimize power with CPU, lighting, and fan settings.
  • Digi+ VRM control - Real-time voltage control.





Enhanced DDR5 performance

Comprehensive memory tuning options are the cornerstone of PRIME motherboards. The PRIME X870-P maximizes the potential of your DDR5 modules, from entry-level to extreme-speed kits.
For entry-level modules without EXPO™ support, ASUS Enhanced Memory Profile (AEMP) automatically detects memory chips and provides optimized profiles for enhanced performance.
For those looking to surpass stock DDR5 speeds, the PRIME X870-P offers extensive AMD Extended Profiles for Overclocking (EXPO™) support and a wide array of UEFI settings for further performance tweaks.






Four M.2 slots (up to 128 Gbps)

PRIME X870-P offers a total of four M.2 slots, including one that supports data-transfer speeds of up to 128 Gbps via PCIe 5.0, two that support 64 Gbps via PCIe 4.0, and one that supports PCIe 3.0. This enables quicker boot-up and app load times with OS or application drives.






Cooler by design

The PRIME X870-P motherboard is engineered with multiple onboard heatsinks and an array of hybrid fan headers to help ensure your rig stays cool and stable under intense workloads.
  • ASUS Fan Xpert 4 - ASUS Fan Xpert 4 software offers comprehensive control over fans and AIO coolers. Auto-Tuning mode configures settings with one click, while Extreme Quiet mode reduces fan speeds for silent operation during light tasks. Controls are also available via the UEFI BIOS.
  • Cooler compatibility - ASUS AIO coolers offer robust performance, high overclocking potential, bold aesthetics and customizable functionality for new motherboards, empowering you to build your dream gaming rig.
  • AI Cooling II - Optimized thermals and reduced noise via dynamic adjustment of fan speeds, based on CPU temperatures.





Empowering connections

The PRIME X870-P motherboard offers a versatile range of connectivity, including support for PCIe 5.0, Realtek 2.5Gb Ethernet, and an array of USB ports.
  • 2.5Gb Ethernet
  • PCIe 5.0
  • USB 40Gbps
  • PCIe 5.0 slot
  • USB 10Gbps





Personalization

The PRIME X870-P enhances the user experience across the board, from simplifying BIOS setting adjustments to offering customizable RGB lighting controls for a uniquely personal system aesthetic.
  • UEFI BIOS - The UEFI interface delivers easy-to-use configuration options for PC beginners, and advanced features for veterans.
  • ASUS GlideX - Enable seamless screen sharing and control across PCs, tablets, and smartphones via wired or wireless connections, supporting multiple platforms.
  • ASUS DriverHub - Simplify driver management with automatic detection, one-click installation and update for smooth, efficient system performance.
  • Armoury Crate - Customize Aura Sync RGB and control ASUS devices. Includes product registration and updates.
  • Aura Sync - Complete RGB lighting control for enthusiast systems, ensuring seamless synchronization with compatible hardware.
  • Addressable Gen 2 RGB headers - Three addressable Gen 2 headers detect LED counts on compatible RGB devices, automatically adjusting lighting effects accordingly.





DIY Friendly

The PRIME X870-P motherboard features EZ PC DIY innovations that simplify and speed up the PC building process, making DIY easy and convenient.
  • PCIe Slot Q-Release - A physical lever unlocks the first PCIe slot’s security latch with one tap, greatly simplifying the process of detaching a PCIe card from the motherboard when it’s time to upgrade to a new graphics card or other compatible device.
  • M.2 Q-Latch - The innovative ASUS Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools or screws. This design employs a simple locking mechanism to secure the drive and neatly detach it with one tap.
  • Q-LED Core - The Q-LED Core display produces color-coded lights during the Power-On Self-Test (POST) that can help you troubleshoot potential issues.
  • Pre-Mounted I/O Shield - Our pre-installed I/O shield safeguards ports, simplifies the build process, increases functionality and enhances aesthetics for PC DIY enthusiasts.
  • BIOS FlashBack - BIOS FlashBack™ simplifies BIOS updates. Just load the BIOS file onto a FAT32 USB stick, insert it into the BIOS FlashBack™ port, and press a button—no CPU or memory needed.
  • SafeSlot - PCIe 5.0 is twice as fast as PCIe 4.0. ASUS has adapted our SMT manufacturing for the faster SafeSlot, a reinforced metal sheath that ensures secure card installation and faster data speeds.



ASUS
90MB1IT0-M0EAY0
53 Items

Data sheet

.
3 x Addressable Gen 21 x Clear CMOS1 x COM Port1 x Front Panel Audio1 x S/PDIF Out1 x SPI TPM (14-1 pin)1 x 10-1 pin System Panel
Wireless
-
RAM Speeds
Up to 8000+MT/s(OC) with Ryzen 9000 & 8000 & 7000 CPUs
Accessories
2 x SATA 6Gb/s cables1 x M.2 rubber package2 x Screw packages for M.2 SSD1 x Quick start guide
USB Ports Supported
Rear:2 x USB4 (40Gbps) Type-C1 x USB 10Gbps Type-A3 x USB 5Gbps Type-A4 x USB 2.0Front:1 x USB 10Gbps Type-C2 x USB 5Gbps4 x USB 2.0
Storage
2 x SATA III4 x M.2Ryzen 9000 & 7000 CPUs:M.2_1 (2280) - PCIe 5.0 x4Ryzen 8000 CPUs:M.2_1 (2280) - PCIe 4.0 x4X870E Chipset:M.2_2 (2242/2260/2280) - PCIe 4.0 x4M.2_3 (2280 ) - PCIe 4.0 x4M.2_4 (2280 ) - PCIe 3.0 x2
RAID
AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1. RAID 5 Function is only supported by AMD Ryzen 9000 series CPU
Warranty
3 Years
Motherboard Type
Desktop
Form Factor
ATX
Socket
AMD AM5
Chipset
AMD X870
DDR Type
DDR5
RAM Technology
DDR5 (Dual Channel)ECC and Non-ECC, Un-buffered MemorySupports AMD EXPOASUS Enhanced Memory Profile
RAM Slots
4 x DIMM
Maximum Memory
192GB
LAN
2.5GB LAN
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC
Back Panel I/O Ports
2 x USB4 (40Gbps) Type-C1 x USB 10Gbps Type-A3 x USB 5Gbps Type-A4 x USB 2.01 x HDMI1 x Realtek 2.5Gb Ethernet3 x Audio jacks1 x BIOS FlashBack button
Internal I/O Connectors
1 x 4-pin CPU Fan1 x 4-pin CPU OPT Fan1 x 4-pin AIO Pump4 x 4-pin Chassis Fan1 x 24-pin Main2 x 8-pin +12V CPU4 x M.2 (Key M)2 x SATA 6Gb/s1 x USB 10Gbps Type-C1 x USB 5Gbps2 x USB 2.0
CPU Support
AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
Package Type
Retail
Graphics Ports
1 x HDMI2 x USB4 (40Gbps) support USB Type-C display outputs
Additional Features
See Overview
Graphics
Integrated GraphicsGraphics specifications may vary between CPU types
M.2 Slot(s)
Yes (M.2)
No. LAN Ports
1 x LAN
Max LAN Speed
2.5GB LAN
PCI/PCI Express
Ryzen 9000 & 7000 CPUs:1 x PCIe 5.0 x16 (supports x16 mode)Ryzen 8000 CPUs:1 x PCIe 4.0 x16 (supports x8/x4 mode)AMD X870 Chipset:2 x PCIe 4.0 x16 (supports x1 mode)
