Tenda TEG1005D 5-Port Metal Cased Gigabit Desktop Switch

TEG1005D is a 5 port Gigabit ethernet switch with a integrated lightning protection circuit that offers 4KV lightning protection to each port to effectively prevent lightning-induced current from damaging the ports or switch, so as to ensure IP camera surveillance system stability.

Lightning protection for each port
Integrated with a professional lightning protection circuit that offers 4KV lightning protection to each port to effectively prevent lightning-induced current from damaging the ports or switch, so as to ensure the surveillance system stability.

Extraordinary heat dissipation
A housing made of 0.8 mm galvanized industrial-grade steel plates for excellent durability has a good heat dissipation performance, which can ensure stable switch operation, a long service life, and more reliable outdoor security surveillance.

Stay connected for 7x24 hours
5 x 10/100/1000Mbps auto-negotiation RJ45 ports that support wire-speed forwarding and large-capacity cache, ensuring smooth surveillance video playback and stable data transmission for 7x24 hours.

User-friendly design
RJ45 ports and LED indicators are located on the same side and aligned vertically for more intuitively showing network status. The RJ45 ports and the power port are designed in the same orientation to reduce the mounting space requirement, allowing the switch to fit into the slimmest outdoor weak current box.

Other features
- Full-duplex working mode
- Auto MDI/MDIX
- Wall mounting
- Plug and play

Standard & Protocol
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE802.3ab

Transmission Media
100BASE-TX/1000BASE-T: Cat.5, Cat.5e or Above100mUTP/STP

Interface
5 x 10/100/1000Mbps auto-negotiation RJ45 ports, auto MDI/MDIX

Lightning Protection
6KV for 5 Ports

LED
1 x power LED5*10/100/1000Mbps Link/Act LEDs

Dimension ( W x D x H )
100 x 64 x 25 mm

Forwarding Mode
Store-and-Forward

MAC Address Table
2K

Forwarding Rate
10BASE-T14881pps/port
100BASE-TX148810pps/port
1000BASE-T1488100pps/port

Backbound Bandwidth
10Gbps

Power Input
100~240V AC50/60Hz

Power Output
5V DC0.6A

Temperature
Operation Temperature:-10C~45C
Storage Temperature: -40C~70C

Humidity
Operation Humidity:10%~90% RHnon-condensing
Storage Humidity:5%~90% RHnon-condensing
